I Only Had One Open Port - Here’s How I Hosted Multiple Node.js Backends with Nginx and systemd

Summary

When my university gave me a VM to host my project, I was excited, until I realized only port 3000 was open. I had multiple Node.js backends to run, and I didn’t want to keep using tmux forever.

This document explains how to host multiple Node.js backend applications on a single port (3000) using Nginx as a reverse proxy and systemd for process management.

The setup was done on an Arch Linux VM with only port 3000 open externally.
Initially, the backend was run using tmux, which worked but wasn’t sustainable for production, switching to systemd provided persistence, auto-restart, and easy service control.

We also faced several routing issues with Nginx (404, 301, double slashes), which were resolved step by step.
This document includes the complete thought process, key problems, and the final working configuration.

Environment Overview

• OS: Arch Linux (VM)
• Public Port Allowed: 3000
• Services Used: Node.js, Nginx, systemd
• Frontend: React (Vite)
• Backend: Express.js API (running on internal ports, proxied via Nginx)

Step 1: Node.js Backend Setup

Example backend (server.js):

import express from "express";
const app = express();

app.use(express.json());

app.get("/", (req, res) => {
  res.send("Task Manager API is running...");
});

app.post("/api/auth/login", (req, res) => {
  res.status(400).json({ message: "Invalid credentials" });
});

const PORT = process.env.PORT || 3001;
app.listen(PORT, "0.0.0.0", () => {
  console.log(`Server is running on port ${PORT}`);
});

The backend runs internally on port 3001, Nginx will later forward traffic from port 3000 to this.

Step 2: Running Node with systemd

1. Create a service file:

sudo nano /etc/systemd/system/taskmanager.service

2. Add the following configuration:

[Unit]
Description=Task Manager Backend Service
After=network.target

[Service]
Type=simple
User=mgug
WorkingDirectory=/home/mgug/backend
ExecStart=/usr/bin/node server.js
Restart=on-failure

[Install]
WantedBy=multi-user.target

3. Enable and start the service:

sudo systemctl daemon-reload
sudo systemctl enable --now taskmanager.service

4. Check status:

sudo systemctl status taskmanager

✅ Result: The service runs 24/7, restarts automatically, and no longer depends on your SSH session.

Step 3: Viewing Logs with journalctl

To view logs for your backend service:

sudo journalctl -u taskmanager -f

• -u taskmanager → logs for that specific systemd unit
• -f → follow live logs (like tail -f)

To view older logs:

sudo journalctl -u taskmanager --since "2025-10-09 00:00:00"

This replaces the need to manually log to files or rely on console output.

Step 4: (Optional) Running with tmux

Originally, the backend was started using tmux:

tmux new -s backend
node server.js

and detached with:

Ctrl + B, D

✅ Pros:

• Keeps session alive even after SSH logout
• Easy to view and manage manually

❌ Cons:

• Manual restart needed after reboots
• No automatic crash recovery
• Difficult to manage multiple backends

Hence, systemd was chosen for long-term reliability and automation.

Step 5: Nginx Configuration

1. Install and enable Nginx:

sudo pacman -S nginx
sudo systemctl enable --now nginx

2. Verify it’s running:

curl http://localhost

Expected output: Nginx welcome page.

3. Create an Nginx site config:

sudo nano /etc/nginx/sites-available/taskmanager-api.conf

Add the following:

server {
    listen 3000;
    server_name _;

    location /api {
        proxy_pass http://127.0.0.1:3001;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection 'upgrade';
        proxy_set_header Host $host;
        proxy_cache_bypass $http_upgrade;
    }
}

Then enable it:

sudo ln -s /etc/nginx/sites-available/taskmanager-api.conf /etc/nginx/sites-enabled/
sudo nginx -t
sudo systemctl reload nginx

✅ Key Point:
The absence of a trailing slash in proxy_pass ensures that /api is preserved when forwarding.
If you add a slash (proxy_pass http://127.0.0.1:3001/;), /api gets stripped from the path.

Step 6: Testing the API

Test with curl:

curl -i -X POST http://localhost:3000/api/auth/login      -H "Content-Type: application/json"      -d '{"email":"test@example.com","password":"123456"}'

Expected output:

HTTP/1.1 400 Bad Request
{"message":"Invalid credentials"}

✅ This confirms Nginx → Node → Express routing works perfectly.

Step 7: Frontend (React + Vite) Proxy Setup

In vite.config.js:

export default defineConfig({
  server: {
    host: "0.0.0.0",
    port: 5173,
    proxy: {
      "/api": {
        target: "http://139.168.xxx.xx:3000",
        changeOrigin: true,
      },
    },
  },
});

This allows the frontend (running on port 5173) to make requests to /api/..., which are proxied to the backend through Nginx on port 3000.

Step 8: Adding Another App

To run multiple apps on the same port (e.g., /newapp):

1. Create a second backend (e.g., runs on port 3002)
2. Add another systemd service (newapp.service)
3. Update Nginx config:

location /api {
    proxy_pass http://127.0.0.1:3001;
}

location /newapp {
    proxy_pass http://127.0.0.1:3002;
}

Then reload:

sudo nginx -t
sudo systemctl reload nginx

Now:

• http://your-ip:3000/api/... → backend 1
• http://your-ip:3000/newapp/... → backend 2

All served securely via the same public port.

Key Problems Faced & Solutions

Final Directory Structure

/home/mgug/
 ├── backend/
 │    ├── server.js
 │    └── package.json
 ├── newapp/
 │    ├── server.js
 │    └── package.json
/etc/systemd/system/
 ├── taskmanager.service
 ├── newapp.service
/etc/nginx/sites-available/
 ├── taskmanager-api.conf
/etc/nginx/sites-enabled/
 ├── taskmanager-api.conf → ../sites-available/taskmanager-api.conf

✅ Final Notes

• systemd ensures reliability, autostart, and easy monitoring (journalctl).
• nginx allows scalable multi-app routing on a single port.
• The /api vs / path issue is a common proxy mistake, remember:
  • Trailing slash removes path prefix
  • No slash preserves it
• tmux is still useful for quick testing or debugging, but not for persistent services.

Commands Cheat Sheet

Authored by: Achyutem Dubey Documented for internal developer use and VM-based deployments.
